2017 Aluminum Sheet Plate

Chemical composition of 2017 aluminum alloy

●Aluminum (Al): balance
●Silicon (Si):0.2-0.8%
●Ferrum (Fe): 0.7% max
●Copper (Cu): 3.5-4.5%
●Manganese (Mn): 0.4-1.0%
●Magnesium (Mg): 0.4-0.8%
●Chromium (Cr): 0.1% max
●Zinc (Zn): 0.25% max
●Titanium (Ti): 0.15% max
●Other elements: Each 0.05% max, Total 0.1% max

Typical mechanical properties of 2017 T4 aluminum

(The values are typical or min values,for reference only.)

2017 aluminum plate application

Aluminum plat 2017 was widely used in various industries and applications due to its unique properties such as lightweight, durability, and corrosion resistance.

Applications of aluminum sheet 2017 were:general mechanical parts, structural and transport tools structural parts, rivets,propellers and accessories for aircraft.
