5056 Aluminum Sheet Plate

Chemical composition of 5056 aluminum alloy

●Aluminum (Al): balance
●Silicon (Si): 0.3% max
●Ferrum (Fe): 0.4% max
●Copper (Cu): 0.1% max
●Manganese (Mn): 0.05-0.2%
●Magnesium (Mg): 4.5-5.6%
●Chromium (Cr): 0.05-0.2%
●Zinc (Zn): 0.1% max
●Other elements: Each 0.05% max, Total 0.15% max

Typical mechanical properties of 5056 H112 aluminum

●Tensile strength: 270 MPa
●Yield strength: 200 MPa
●Elongation: 12%
●Hardness (Brinell): 80 HB

(The values are typical or min values,for reference only.)

5056 aluminum sheet plate application

5056 aluminum is a high-strength aluminum alloy with good corrosion resistance and weldability. Its primary alloying element is magnesium, which gives it its high strength and good machinability.

Common applications of 5056 aluminum plate
Marine:  boat hulls and other structures that are exposed to saltwater.
Aerospace: aircraft components and satellite structures.
Automotive:  vehicle frames, suspension components, and body panels.
Pressure vessels,Welding and brazing,Structural applications
