LS-4100BNC Precision Circular Saw Machine with Mechanical Tension Engine-Driven 18.5KW Motor High-Accuracy Cutting

LS-4100BNC Precision Circular Saw Machine with Mechanical Tension Engine-Driven 18.5KW Motor High-Accuracy Cutting

Introduction

Model		LS-4100BNC
Sawing ability	Cutting length	4100 mm
	cutting width	4100 mm
	Maximum cutting high	200mm
	Maximum exposure height of saw blade	205mm
sawing machine	Main saw motor	18.5KW
	Main saw diameter	630mm
	Main saw shaft core diameter	38mm
	Main saw speed	3000 r/min
Saw seat	Walking variable frequency motor	2KW
	Forward speed	9m/min
	reverse speed	17 m/min
	Automatic feeding motor	AC1.0KW
	Use air pressure	>5.0 kg/cm2
	The height of the workbench above the ground	1000mm
	Machine toal dimensions (length x width x high)	7800mmx6630mmx2470mm
	Voltage	380V/50HZ

The equipment consists of three major parts, including the host, the front feeding table and the rear ruler frame. PLC servo control system makes equipment operation simple and convenient. The adjustable saw head structure can meet the cutting needs of different thicknesses of boards. The micro oil mist fuel injection system provides better assistance in cooling and lubricating the saw blade. The device is easy and convenient to operate.
